Description
802.1X; ARP; DDNS; DHCP; DNS; Easy DDNS; HTTP; HTTPS; ICMP; IGMP; IPv4; IPv6; Multicast; NTP; RTCP; RTP; RTSP; SRTP; SSH; TLSv1.2; TCP/IP; UDP; Unicast; UPnP. Video Loss; Network Disconnected; No Disk; Illegal Access; Disk group space alert; Disk Full; Disk R/W Error; Recording Abnormal; Abnormal found in smart of disk; Abnormal temperature of the disk; Voltage Alarm(IPC); RTC Failure; IP Address Conflict; MAC Address Conflict.
Key features
- Access Channel
- Incoming Bandwidth
- Outgoing Bandwidth
- Preview Decoding Capability
- Playback Decoding Capability
- Third-party Camera Access
- ONVIF(Profile S/T); RTSP
- HDMI: 1024×768(60Hz), (720P )1280×720(50Hz/60Hz), 1280×800(60Hz), 1366×768(60Hz), 1440×900(60Hz), (1080P)1920×1080(50Hz/60Hz), (4K)3840×2160(30Hz)
- VGA: 1024×768(60Hz), (720P )1280×720(50Hz/60Hz), 1280×800(60Hz), 1366×768(60Hz), 1440×900(60Hz), (1080P)1920×1080(50Hz/60Hz)
- Compression
- Stream Type
- Mobile Phone Access
- Rtsp; CGI; SDK
- Web
- Record Playback
- Multi-channel Playback
- Record Mode
- Manual Recording; Alarm Recording; Schedule Recording
- Local HDD
- Backup
- Playback Function
- Play/Pause/Stop/Slow/Speed/Backwards 30s/Forwards 30s/Full Screen/Backup (Video Editing)/Step/Digital Zoom/Instant Replay
- Alarm
- Motion Detection; Mask Alarm; Alarm Input(IPC)
- Exceptions Alarm
- Intelligent Analytics
- Tripwire; Double Tripwire; Perimeter; Object Abandon; Object Missing; Running; Parking; Video Abnormal; Audio Abnormal; On Duty Detection; Crowd Detection; Smart Motion; Human/Vehicle Classification; Loitering
- VCA Search
- Early-warning Search
- HDD Capacity
- Up to 10 TB capacity for each HDD
- Disk Group
- Hdmi
- VGA
- Sata
- UI Language
- English; Spanish; Italian; Turkish; French; Polish; Hebrew; German; Portuguese; Greek
- NetWeight
- GrossWeight
- Network Video Recorder; Screw Pack; Mouse; Power Adapter; European Standard Power Cord
Specifications
- I/B/V3.0
- 10
- 60Mbps
- 40Mbps
- Resolution
- 6mp/5mp/4mp/3mp/1080p/uxga/720p/vga/4cif/dcif/2cif/cif/qcif
- 6MP(30fps)×1, 5MP(30fps)×1, 4MP(30fps)×2, 3MP(30fps)×2, 1080P(30fps)×4, 720P(30fps)×8, 4CIF(30fps)×10
- 6MP(30fps)×1, 5MP(30fps)×1, 4MP(30fps)×1, 3MP(30fps)×2, 1080P(30fps)×3, 720P(30fps)×4
- Simultaneous Output: VGA: 1/2A/2B/3/4/5/6/7/8/9/10 HDMI: 1/2A/2B/3/4/5/6/7/8/9/10
- 1-ch, RCA (Linear, 1 K’d9)
- S+265; H.265; S+264; H.264
- G711A; G711U; adpcm_div4
- Android; iOS; P2P
- IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+
- 4
- 1 Disk Group
- 2×USB2.0
- 1×HDMI(supports up to 4K resolution output)
- 1×VGA
- 1×RJ-45, 10/100 Mbps self-adaptive Ethernet port
- 1×SATA interface
- DC12V 3.33A
- <10W(HDD not included, idling)
- 0.8 kg
- 1.45 kg
- 255(L)231(W)45(H)mm
- 385(L)80(W)280(H)mm
- 10℃~+55℃ (+14℉~+131℉)
- 10%~90%RH (non-condensing)
- 20℃~+60℃ (-4℉~+140℉)
