Description
8MP(30fps)×2, 6MP(30fps)×2, 5MP(30fps)×3, 4MP(30fps)×4, 3MP(30fps)×5, 1080P(30fps)×8, 720P(30fps)×16, 4CIF(30fps)×20; *: The length or width of camera resolution (each track) cannot exceed 4096 pixels. 802.1X; ARP; DDNS; DHCP; DNS; Easy DDNS; FTP; HTTP; HTTPS; ICMP; IGMP; IPv4; IPv6; Multicast; NFS; NTP; PPPoE; QoS; RTCP; RTP; RTSP; SMB/CIFS; SMTP; SNMP v1/v2/v3; SRTP; SSH; SSL; TLSv1.2; TCP/IP; UDP; Unicast; UPnP.
Key features
- Access Channel
- Incoming Bandwidth
- Outgoing Bandwidth
- Preview Decoding Capability
- Playback Decoding Capability
- Third-party Camera Access
- ONVIF(Profile S/T); RTSP
- HDMI: 1024×768(60Hz), (720P )1280×720(50Hz/60Hz), 1280×800(60Hz), 1440×900(60Hz), (1080P)1920×1080(50Hz/60Hz), (2K)2560×1440(30Hz), (4K)3840×2160(30Hz)
- Compression
- Stream Type
- Mobile Phone Access
- ONVIF(Profile S/T/G); RTSP; CGI; SDK
- Web
- Record Playback
- Multi-channel Playback
- Record Mode
- Manual Recording; Alarm Recording; Schedule Recording
- Local HDD
- Backup
- Playback Function
- Play/Pause/Stop/Reverse/Slow/Speed/Backwards 30s/Forwards 30s/Full Screen/Backup (Video Editing)/Step/Digital Zoom/Instant Replay
- Dual Stream Record
- Yes
- Alarm
- Motion Detection; Mask Alarm; Alarm Input(IPC); Alarm Input(NVR)
- Exceptions Alarm
- Video Loss; Network Disconnected; No Disk; Illegal Access; Disk group space alert; Disk Full; Disk R/W Error; Recording Abnormal; Abnormal found in smart of disk; Abnormal temperature of the disk; Hot-spare Exception; Voltage Alarm(IPC); RTC Failure; IP Address Conflict; MAC Address Conflict
- Intelligent Analytics
- Tripwire; Double Tripwire; Perimeter; Object Abandon; Object Missing; Running; Parking; Video Abnormal; Audio Abnormal; On Duty Detection; Crowd Detection; People Counting; Face Detection; Smart Motion; Human/Vehicle Classification; Loitering
- VCA Search
- Early-warning Search; Behavior Search; Face Search
- Face Detection
- Face Attributes
- Gender; Age
- HDD Capacity
- Up to 10 TB capacity for each HDD
- Disk Group
- Hdmi
- VGA
- Sata
- Alarm I/O
- 4-ch, TTL inputs, 3mA, 3.3VDC; 1-ch, relay output, 1A, 24VDC
- UI Language
- Simple Chinese; Traditional Chinese; English; Spanish; Korean; Italian; Turkish; Russian; Thai; French; Polish; Dutch; Hebrew; Arabic; Vietnamese; German; Ukrainian; Portuguese; Albanian; Indonesian; Greek
- NetWeight
- GrossWeight
- Network Video Recorder; Screw Pack; Mouse; Power Adapter; European Standard Power Cord
Specifications
- I/b/k/v3.1
- 20
- 80Mbps
- Resolution
- 8mp/6mp/5mp/4mp/3mp/1080p/uxga/720p/vga/4cif/dcif/2cif/cif/qcif
- 8MP(30fps)×2, 6MP(30fps)×2, 5MP(30fps)×3, 4MP(30fps)×4, 3MP(30fps)×5, 1080P(30fps)×8, 720P(30fps)×16
- VGA: 1024×768(60Hz), (720P )1280×720(50Hz/60Hz), 1280×800(60Hz), 1440×900(60Hz), (1080P)1920×1080(50Hz/60Hz)
- Simultaneous Output: VGA: 1/2A/2B/3/4/5/6/7/8/9/10/12/13/16/20A/20B/20C/20D/25 HDMI: 1/2A/2B/3/4/5/6/7/8/9/10/12/13/16/20A/20B/20C/20D/25
- 1-ch, 3.5mm
- 1-ch, RCA (Linear, 1 K’d9)
- 1-ch, 3.5mm, using the audio input
- S+265; H.265; S+264; H.264
- G711A; G711U; AAC; adpcm_div4
- Android; iOS; P2P
- IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+
- 16
- 1 Disk Group
- 2×USB2.0
- 1×HDMI(supports up to 4K resolution output)
- 1×VGA
- 1×RJ-45, 10/100 Mbps self-adaptive Ethernet port
- 1×SATA interface
- DC12V 3.33A
- <10W(HDD not included, idling)
- 0.9 kg
- 1.6kg
- 255(L)231(W)45(H)mm
- 385(L)80(W)280(H)mm
- 10℃~+55℃ (+14℉~+131℉)
- 10%~90%RH (non-condensing)
- 20℃~+60℃ (-4℉~+140℉)
